Zhaoyi Wang
(汪昭义)

Landslide monitoring is essential for understanding geohazards and mitigating associated risks. However, existing point cloud-based methods typically rely on either geometric or radiometric information and often yield sparse or non-3D displacement estimates. In this paper, we propose a hierarchical partition-based coarse-to-fine approach that fuses 3D point clouds and co-registered RGB images to estimate dense 3D displacement vector fields. We construct patch-level matches using both 3D geometry and 2D image features. These matches are refined via geometric consistency checks, followed by rigid transformation estimation per match. Experimental results on two real-world landslide datasets demonstrate that our method produces 3D displacement estimates with high spatial coverage (79% and 97%) and high accuracy. Deviations in displacement magnitude with respect to external measurements (total station or GNSS observations) are 0.15 m and 0.25 m on the two datasets, respectively, and only 0.07 m and 0.20 m compared to manually derived references. These values are below the average scan resolutions (0.08 m and 0.30 m). Our method outperforms the state-of-the-art method F2S3 in spatial coverage while maintaining comparable accuracy. Our approach offers a practical and adaptable solution for TLS-based landslide monitoring and is extensible to other types of point clouds and monitoring tasks.

Point cloud registration has seen significant advancements with the application of deep learning techniques. However, existing approaches often overlook the potential of integrating radiometric information from RGB images. This limitation reduces their effectiveness in aligning point clouds pairs, especially in regions where geometric data alone is insufficient. When used effectively, radiometric information can enhance the registration process by providing context that is missing from purely geometric data. In this paper, we propose CoFF, a novel Cross-modal Feature Fusion method that utilizes both point cloud geometry and RGB images for pairwise point cloud registration. Assuming that the co-registration between point clouds and RGB images is available, CoFF explicitly addresses the challenges where geometric information alone is unclear, such as in regions with symmetric similarity or planar structures, through a two-stage fusion of 3D point cloud features and 2D image features. It incorporates a cross-modal feature fusion module that assigns pixel-wise image features to 3D input point clouds to enhance learned 3D point features, and integrates patch-wise image features with superpoint features to improve the quality of coarse matching. This is followed by a coarse-to-fine matching module that accurately establishes correspondences using the fused features. We extensively evaluate CoFF on four common datasets: 3DMatch, 3DLoMatch, IndoorLRS, and the recently released ScanNet++ datasets. In addition, we assess CoFF on specific subset datasets containing geometrically ambiguous cases. Our experimental results demonstrate that CoFF achieves state-of-the-art registration performance across all benchmarks, including remarkable registration recalls of 95.9% and 81.6% on the widely-used 3DMatch and 3DLoMatch datasets, respectively. CoFF is particularly effective in scenarios with challenging geometric features, provided that RGB images are available and that the overlapping regions exhibit sufficient texture in the RGB images.

Estimating 3D deformation with high spatial resolution from TLS point clouds is beneficial for geomonitoring. Existing methods for this task primarily rely on geometric data. They do not use radiometric information although it is often available as well. This leaves potential for improvement. To address this, we propose an approach that utilizes RGB images—captured by built-in cameras of TLS scanners and co-registered with TLS point clouds—to generate dense 3D displacement vector fields for deformation analysis. Our method comprises three main steps: (1) applying the Efficient-LoFTR algorithm to establish dense 2D pixel correspondences on RGB images across two epochs; (2) projecting 3D points from both epochs onto RGB images and establishing 3D point correspondences by matching the projected pixels with the established 2D correspondences; (3) clustering the point cloud of one epoch and refining the 3D point correspondences within each cluster to produce the final displacement vector fields. Experiments on real measurements obtained from a rockfall simulator and from a real-world landslide demonstrate that our method achieves comparable accuracy to state-of-the-art geometry-based methods, with improved density and computational efficiency. By using radiometric features, our approach complements geometry-based methods, suggesting that combining both will enhance coverage and/or accuracy for geomonitoring applications.

The integration of the color information from RGB cameras with the point cloud geometry is used in numerous applications. However, little attention has been paid on errors that occur when aligning colors to points in terrestrial laser scanning (TLS) point clouds. Such errors may impact the performance of algorithms that utilize colored point clouds. Herein, we propose a procedure for assessing the alignment between the TLS point cloud geometry and colors. The procedure is based upon identifying artificial targets observed in both LiDAR-based point cloud intensity data and camera-based RGB data, and quantifying the quality of the alignment using differences between the target center coordinates estimated separately from these two data sources. Experimental results with eight scanners show that the quality of the alignment depends on the scanner, the software used for colorizing the point clouds, and may change with changing environmental conditions. While we found the effects of misalignment to be negligible for some scanners, they exhibited clearly systematic patterns exceeding the beam divergence, image and scan resolution for four of the scanners. The maximum deviations were about 2 mrad perpendicular to the line-of-sight when colorizing the point clouds with the respective manufacturer’s software or scanner in-built functions, while they were up to about 5 mrad when using a different software. Testing the alignment quality, e.g., using the approach presented herein, is thus important for applications requiring accurate alignment of the RGB colors with the point cloud geometry.
